MAOverlayPathRenderer Class Reference
该类设置overlay绘制的属性，可以使用该类的子类MACircleRenderer, MAPolylineRenderer, MAPolygonRenderer或者继承该类 More...
#import <MAOverlayPathRenderer.h>
Inheritance diagram for MAOverlayPathRenderer:
Properties | |
| UIColor * | fillColor |
| 填充颜色,默认是kMAOverlayRendererDefaultFillColor (注意：只有绘制多边形时有效，为填充色) More... | |
| UIColor * | strokeColor |
| 笔触颜色,默认是kMAOverlayRendererDefaultStrokeColor More... | |
| CGFloat | lineWidth |
| 笔触宽度, 单位屏幕点坐标，默认是0 More... | |
| MALineJoinType | lineJoinType |
| LineJoin,默认是kMALineJoinBevel. More... | |
| MALineCapType | lineCapType |
| LineCap,默认是kMALineCapButt. More... | |
| MALineDashType | lineDashType |
| 虚线类型 More... | |
 Properties inherited from MAOverlayRenderer | |
| id< MAOverlayRenderDelegate > | rendererDelegate |
| 由地图添加时，不要手动设置。如果不是使用map进行添加，则需要手动设置。 More... | |
| NSInteger | zIndex |
| z值，大值在上，默认为1。覆盖物的叠加顺序。默认叠加顺序，先添加的在底层，后添加的在上层。默认为10 More... | |
| id< MAOverlay > | overlay |
| 关联的overlay对象 More... | |
| CGFloat | alpha |
| 透明度[0，1]，默认为1。 More... | |
| BOOL | isVisible |
| 是否可见，默认为YES More... | |
Additional Inherited Members | |
| Instance Methods inherited from MAOverlayRenderer | |
| (instancetype) | - initWithOverlay: |
| 初始化并返回一个Overlay Renderer More... | |
| (void) | - setNeedsUpdate |
| 当关联overlay对象有更新时，调用此接口刷新. More... | |
Detailed Description
该类设置overlay绘制的属性，可以使用该类的子类MACircleRenderer, MAPolylineRenderer, MAPolygonRenderer或者继承该类
Property Documentation
◆ fillColor
|
readwritenonatomicretain |
填充颜色,默认是kMAOverlayRendererDefaultFillColor (注意：只有绘制多边形时有效，为填充色)
◆ lineCapType
|
readwritenonatomicassign |
LineCap,默认是kMALineCapButt.
◆ lineDashType
|
readwritenonatomicassign |
虚线类型
◆ lineJoinType
|
readwritenonatomicassign |
LineJoin,默认是kMALineJoinBevel.
◆ lineWidth
|
readwritenonatomicassign |
笔触宽度, 单位屏幕点坐标，默认是0
◆ strokeColor
|
readwritenonatomicretain |
笔触颜色,默认是kMAOverlayRendererDefaultStrokeColor
The documentation for this class was generated from the following file:
