#import <MACustomBuildingOverlay.h>
Instance Methods | |
| (BOOL) | - setOptionWithCoordinates:count: |
| 重新设置option范围. Reset the option range More... | |
 Instance Methods inherited from MAMultiPoint | |
| (void) | - getCoordinates:range: |
| 将内部的坐标点数据转化为经纬度坐标并拷贝到coords内存中 Convert the internal coordinate point data into latitude and longitude coordinates and copy them to the coords memory More... | |
| Instance Methods inherited from <MAOverlay> | |
| (CLLocationCoordinate2D) | - coordinate |
| (MAMapRect) | - boundingMapRect |
| Instance Methods inherited from <MAAnnotation> | |
| (void) | - setCoordinate: |
| 设置标注的坐标，在拖拽时会被调用. Set the coordinates of the annotation, which will be called during dragging More... | |
Class Methods | |
| (instancetype) | + optionWithCoordinates:count: |
| 根据经纬度坐标数据生成楼块显示选项option Generate building block display options based on latitude and longitude coordinate data More... | |
Properties | |
| CGFloat | height |
| CGFloat | heightScale |
| UIColor * | topColor |
| UIColor * | sideColor |
| BOOL | visibile |
| Properties inherited from MAMultiPoint | |
| MAMapPoint * | points |
| NSUInteger | pointCount |
| BOOL | cross180Longitude |
| Properties inherited from MAShape | |
| NSString * | title |
| 标题 Title More... | |
| NSString * | subtitle |
| 副标题 Subtitle More... | |
| Properties inherited from MABaseOverlay | |
| CLLocationCoordinate2D | coordinate |
| MAMapRect | boundingMapRect |
| double | altitude |
| Properties inherited from <MAAnnotation> | |
| NSString * | title |
| NSString * | subtitle |
| double | altitude |
Additional Inherited Members | |
| Protected Attributes inherited from MAShape | |
| NSString * | _title |
| 标题 Title More... | |
| NSString * | _subtitle |
| 副标题 Subtitle More... | |
| Protected Attributes inherited from MABaseOverlay | |
| double | _altitude |
| 海拔 Elevation More... | |
Detailed Description
该类用于定义一个楼块显示选项. since 6.3.0 This class is used to define a building block display option. since 6.3.0
Method Documentation
◆ optionWithCoordinates:count:
| + (instancetype) optionWithCoordinates: | (CLLocationCoordinate2D *) | coords | |
| count: | (NSUInteger) | count | |
根据经纬度坐标数据生成楼块显示选项option Generate building block display options based on latitude and longitude coordinate data
- Parameters
-
coords 经纬度坐标点数据,coords对应的内存会拷贝,调用者负责该内存的释放 Latitude and longitude coordinate point data, the memory corresponding to coords will be copied, the caller is responsible for releasing this memory count 经纬度坐标点数组个数 Number of latitude and longitude coordinate points array
- Returns
- 新生成的楼块显示选项option Newly generated building block display option
◆ setOptionWithCoordinates:count:
| - (BOOL) setOptionWithCoordinates: | (CLLocationCoordinate2D *) | coords | |
| count: | (NSUInteger) | count | |
重新设置option范围. Reset the option range
- Parameters
-
coords 指定的经纬度坐标点数组, C数组，内部会做copy，调用者负责内存管理 Specified latitude and longitude coordinate points array, C array, internal copy will be made, caller is responsible for memory management count 坐标点的个数 Number of coordinate points
- Returns
- 是否设置成功 Whether the setup was successful
Property Documentation
◆ height
|
readwritenonatomicassign |
楼块的高度. 修改该属性会使option范围内的所有楼块为同一个高度. (范围 (-1 U [1, 1000]). 默认-1,显示为默认高度.) The height of the building block. Modifying this property will set all building blocks within the option scope to the same height. (Range (-1 U [1, 1000]). Default -1, displayed as the default height.
◆ heightScale
|
readwritenonatomicassign |
楼块的高度缩放比例. 修改该属性会使option范围内的所有楼块高度放大或者缩小heightScale倍. (默认1. 如果指定了height则此值将被忽略.) The height scaling ratio of the building blocks. Modifying this attribute will scale the height of all building blocks within the option range by a factor of heightScale. (Default is 1. If height is specified, this value will be ignored.)
◆ sideColor
|
readwritenonatomicstrong |
楼块的侧面颜色. (默认[UIColor darkGrayColor], 不支持透明度) The side color of the building block. (Default [UIColor darkGrayColor], transparency not supported)
◆ topColor
|
readwritenonatomicstrong |
楼块的顶面颜色. (默认[UIColor lightGrayColor], 不支持透明度) The top color of the building block. (Default [UIColor lightGrayColor], transparency not supported)
◆ visibile
|
readwritenonatomicassign |
option选项是否可见. (默认YES) Whether the option is visible. (Default: YES)
The documentation for this class was generated from the following file:
